SWINE
SWINE MARKET
Keeping your swine comfortable is top priority and as the leading global manufacturer of innovative heating solutions, we can provide the right products to fit your needs. HeatStar® AG has specifically designed our radiant tube heaters to be extremely efficient and provide uniform distribution of heat in the areas of your barn that need it the most. Our Comforter Heater coupled with the Optimizer reflector spreads out the radiant energy creating symmetrical heat even when it is hung off center. We also offer unit heaters and vent free heaters to provide comfort to other areas of your barn as well. Utilizing our heating solutions in your barns can help you reduce installation-associated and operating costs, improve pig productivity, and increase your return on investment.
SWINE HEAT OPTIONS
Collapsible content
V-Flector™ Swine Brooder
V-Flector™ Swine Brooder
Enhanced Heat Performance
The Heatstar AG® reflector with built-in V-Flector™ technology efficiently reflects the infrared (IR) energy providing an enhanced heat pattern and comfortable space for swine.
V-Flector™ Technology
The V-Flector design utilizes the maximum amount of radiant heat from the burner. The added efficiency allows your facility to reach the desired temperature quickly. The reflector design throws direct heat precisely where needed.
Dual Layer Filter System
The highly durable dual layer system has a hard exterior filter and a fine mesh filter both made of stainless steel. The exterior filter is heavy-duty, while bein easy to clean and maintain. The inner mesh filter keeps out harmful particules.
FEATURES:
- Durable Stainless Steel Construction
- V-Flector™ Technology
- Enhanced Heat Pattern
- Dual Layer Cleanable Filter
- Reinforced Gas Supply
- Chain Link Hanging System
- Easy Maintenance & Cleaning
- Stack-to-Store Design
| Model Number | F170018AG | F170010AG |
| BTU / HR Rating (maximum input) | 17,000 | 10,000 |
| Coverage Area (sq. ft.) | 200 - 300 | 150 - 200 |
| Pig Coverage | 100 | 100 |
| Install Height (ft. from ground) | 4 - 5 | 4 - 5 |
| Filter | Included - 316SS Mesh | Included - 316SS Mesh |
| Operating Pressure LP/NG (PSI) | 5 | 5 |
| Fuel Consumption LP/NG | .79 lbs/hr. / 17 cu. ft./hr. | .46 lbs/hr. / 10 cu. ft./hr. |
| Ignition Type | Manual | Manual |
| Dimensions (in.) | 19L x 8.5W x 8H | 19L x 8.5W x 8H |
| Weight (lbs) | 4 | 4 |
| Clearance to Cumbustibles (ft.) | Top - 3 Sides - 3 Under - 3.5 | Top - 3 Sides - 3 Under - 3.5 |
COMFORTER® Tube Heater Systems
COMFORTER® Tube Heater Systems
The HeatStar® COMFORTER Tube Heater systems utilize infrared technology to strategically direct radiant heat to the ground level cost effectively keeping stock at the desired, comfortable temperatures.
SINGLE STAGE OPTIONS
FEATURES:
- 2-Year Warranty (tubes)
- Sealed burner control box
- 10-ft to 60-ft lengths
- Aluminzed tubing (1st 10-ft)
- Install kit included with tube set
- Connects easily to thermal control systems
- Stainless steel couplers
- Chrome plated hanging brackets
- Direct spark ignition
- (Hot surface ignition available with special order)
BURNER BOXES
*Special Order: CSA certified burner boxes in BTU sizes 40K, 60K, and 80K
TUBE SETS
*Tube sets include: tubes, reflectors, hangers, couplers, tube vent cap, drip line, gas hose, electric cord, and turbulator
*Tube sets are compatible with either Natural Gas or Propane burner boxes
TWO STAGE OPTIONS - AVAILABLE AS SPECIAL ORDER
COMFORTER® Tube Stainless Steel Heater Systems
COMFORTER® Tube Stainless Steel Heater Systems
The HeatStar® AG COMFORTER Stainless Steel Tube Heater systems utilize infrared technology to strategically direct radiant heat to the ground level cost effectively keeping stock at the desired, comfortable temperatures.
SINGLE STAGE OPTIONS
FEATURES:
- 2-Year Warranty (tubes)
- Sealed burner control box
- 10-ft to 60-ft lengths
- Aluminzed tubing (1st 10-ft)
- Install kit included with tube set
- Connects easily to thermal control systems
- Stainless steel couplers
- Chrome plated hanging brackets
- Direct spark ignition
- (Hot surface ignition available with special order)
BURNER BOXES
| Stock Number | F102650SS | F102651SS | F102652SS | F102653SS | F102654SS | F102655SS | F102656SS | F102657SS |
| Model Number | HSAG100N | HSAG60LP | HSAG80N | HSAG80LP | HSAG100N SS | HSAG100LP SS | HSAG125N | HSAG125LP |
| Total Input (BTU) | 60,000 | 60,000 | 80,000 | 80,000 | 100,000 | 100,000 | 125,000 | 125,000 |
| Fuel Type | Natural Gas | Liquid Propane | Natural Gas | Liquid Propane | Natural Gas | Liquid Propane | Natural Gas | Liquid Propane |
TUBE SETS
| Stock Number | F106401AG | F106406AG | F106407AG | ||
| Use with Burner Box Models | HSAG100 | HSAG100 or HSAG125 | HSAG150 | ||
| Length | 30-ft | 40-ft | 50-ft | ||
| Shipping Weight (lbs) | 130 | 150 | 175 |
*Tube sets include: tubes, reflectors, hangers, couplers, tube vent cap, drip line, gas hose, electric cord, and turbulator
*Tube sets are compatible with either Natural Gas or Propane burner boxes
Unit Heaters
Unit Heaters
The HeatStar® Forced Air Unit Heater is efficient and effective convection heat for your swine barn. It comes set for natural gas but includes a propane conversion kit. With easy installation and simple operation, you'll be up and running in no time. We have a range of BTUs from 50,000 to our larger Big Boxx options topping at 400,000 BTU which can heat up to 13,400 sq ft.
FEATURES:
- Ships as NG, includes NG to LP conversion kit
- Spark ignition features self-diagnostic control module
- Includes angle brackets (2) for ceiling mount
- Category I Vertical; Category III Horizontal Venting
- CSA Certified
BIG BOXX SIZES
 |
 |
 |
 |
|
| Stock Number | F163053 | F163054 | F163055 | F163056 |
| Model Number | HSU200NGPSSP | HSU250NGPSSP | HSU300NGPSSP | HSU400NGPSSP |
| Total Input (BTU) | 200,000 | 250,000 | 300,000 | 400,000 |
| Heating Area (Sq Ft) | 6,700 | 8,400 | 10,000 | 13,400 |
| Flue Size | 4-in | 6-in | 6-in | 6-in |
STANDARD SIZES
 |
 |
 |
||
| Stock Number | F160551 | F160561 | F160491 | |
| Model Number | HSU50NG | HSU80NG | HSU125NG | |
| Total Input (BTU) | 50,000 | 80,000 | 125,000 | |
| Heating Area (Sq Ft) | 1,250 | 2,000 | 3,125 | |
| Flue Size | 4-in | 4-in | 4-in |
Vent Free Heaters
Vent Free Heaters
Enjoy the comfort and warm of safe, clean-burning heat. The HeatStar® AG Vent Free heaters are available in a variety of options from blue flame to radiant and natural gas or propane. The electric ignition is powered by 2 AA batteries which allows them to operate without electricity during power outages.
FEATURES:
- Blower fan included on 20K and 30K BTU models - Circulates heat
- Electronic "push-button" ignition
- Thermostat included - Top mounted controls
- Safe - Built-in low oxygen shut-off sensor
- Economical - 99.9% efficient
RADIANT OPTIONS
 |
 |
 |
||
| Propane Stock Number | F155229 / F156001 | F156051 | F156091 | |
| Propane Model Number | HSVFRD10LP / HSSVFRD10LPT | HSSVFRD20LPBT | HSSVFRD30LPBT | |
| Natural Gas Stock Number | F155226 | F156041 | F156081 | |
| Natural Gas Model Number | HSVFRD10NG | HSSVFRD20NGBT | HSSVFRD30NGBT | |
| Total Input (BTU) | 10,000 | 18,000 LP / 20,000 NG | 30,000 | |
| Heating Area (Sq Ft) | 250 | 500 | 750 |
BLUE FLAME OPTIONS
 |
 |
 |
||
| Propane Stock Number | F155583 / F156011 | F156031 | F156071 | |
| Propane Model Number | HSVFBF10LP / HSSVFBF10LPT | HSSVFBF20LPBT | HSSVFBF30LPBT | |
| Natural Gas Stock Number | F155550 | F156021 | F156061 | |
| Natural Gas Model Number | HSVFBF10NG | HSSVFBF20NGBT | HSSVFBF30NGBT | |
| Total Input (BTU) | 10,000 | 20,000 | 30,000 | |
| Heating Area (Sq Ft) | 250 | 500 | 750 |
Hoses
Hoses
Customers have the option to buy coils, such as 200-ft. Hoses available in a range of diameters depending on hose type.
Water Hoses
Our hose is made to be durable, easy to handle, and provide long-lasting service.
Propane & Natural Gas Hoses
All our hose is abrasion resistant for reduced drag over rocks and other forms of ground cover and does not mark on concrete.
Other Heaters and Accessories
Other Heaters and Accessories
Propane Torches
Mr. Heater portable torches are lightweight and easy to use with a convenient smoke-free flame and no fumes.
UTV Heater
Our UTV heater keeps you warm as you check on your livestock.Travel in comfort with our 3,800 BTU heater designed to fit in a cupholder and handle the rolling hills of your land.
Swine Brooder Gas Manifold
Our manifold works with NG and LP units by connecting to the electronic control system.
