POULTRY

POULTRY MARKET

Radiant Tube Heaters from Heatstar AG® deliver low-intensity, gentle heat to evenly distribute heat to the floor which, in turn, heats the surrounding air. Even heat is the key to providing a comfortable space where broilers can eat, drink, and grow. Their comfort level directly effects the feed to conversion ratio. This means that the more comfortable your birds are, the better they will grow and increase your return on investment.

POULTRY HEAT OPTIONS

From egg room to whole house brooding, we have multiple options available. Click to expand.

JET Tube Heater Systems

The JET™ radiant tube heater system was designed to provide superior heating with an even floor heat pattern. JET™ heaters use a burner with a 10-ft (3.05 meter) jet-like flame combined with a unique 25-ft (7.62meter) or 20-ft (6.10 meter) tube system to provide strong, even heat across the poultry house floor. Designed for ease of use, the burner box has an easy access panel, the gasket lined burner manages dust and reduces maintenance, while the operating and power lights are easily visible from the ground.

FEATURES:

Burner Box creates a 10-ft "jet-like" flame
Tubes install easily as Straight or U-Tube configuration
Tubes have full cover polished aluminum reflector
Outside or inside air for combustion

BURNER BOXES

Stock Number	F102080	F102085	F102090	F102095
Use with Burner Box Models	JET20NG	JET20LP	JET25NG	JET25LP
Total Input (BTU)	20,000	20,000	25,000	25,000
Fuel Type	Natural Gas	Liquid Propane	Natural Gas	Liquid Propane

TUBE SETS

Stock Number	F106020	F106025
Model Number	JET20TB	JET25TB
Use with Burner Box Models	20-ft JET Tube Set, 3-in to 3.5-in	25-ft JET Tube Set, 3.5-in to 4-in

*Tube sets are compatible with either Natural Gas or Propane burner boxes

Unit Heaters

The HeatStar® AG Forced Air Unit Heater is efficient and effective convection heat for the non-livestock areas of your buildings. It comes set for natural gas but includes a propane conversion kit. With easy installation and simple operation, you'll be up and running in no time. We have a range of BTUs from 50,000 to our larger Big Boxx options topping at 400,000 BTU which can heat up to 13,400 sq ft. The standards sizes allow for installation with low profiles and 1-in clearance.

FEATURES:

Ships as NG, includes NG to LP conversion kit
Spark ignition features self-diagnostic control module
Includes angle brackets (2) for ceiling mount
Category I Vertical; Category III Horizontal Venting
CSA Certified

BIG BOXX SIZES - Stainless Steel


Stock Number	F163053	F163054	F163055	F163056
Model Number	HSU200NGPSSP	HSU250NGPSSP	HSU300NGPSSP	HSU400NGPSSP
Total Input (BTU)	200,000	250,000	300,000	400,000
Heating Area (Sq Ft)	6,700	8,400	10,000	13,400
Flue Size	4-in	6-in	6-in	6-in

STANDARD SIZES

Stainless Steel Separated Combustion

Stock Number	F163033	F163034	F163035	F163036
Model Number	HSU200NGPSS	HSU250NGPSS	HSU300NGPSS	HSU400NGPSS
Total Input (BTU)	200,00	250,000	300,000	400,000
Heating Area (Sq Ft)	6,700	8,400	10,000	13,400
Flue Size

Aluminized Exchangers

Stock Number	F163033	F163042	F163063	F163043
Model Number	HSU150NGPALP	HSU150NGPAL	HSU200NGPALP	HSU200NGPAL
Total Input (BTU)	150,000	150,000	200,000	200,000
Heating Area (Sq Ft)	5,000	5,000	6,700	6,700
Flue Size


Stock Number	F160551	F160561	F160491
Model Number	HSU50NG	HSU80NG	HSU125NG
Total Input (BTU)	50,000	80,000	125,000
Heating Area (Sq Ft)	1,250	2,000	3,125
Flue Size	4-in	4-in	4-in

Optimizer™ Reflector

The Optimizer™ reflector coupled with the JET™ burner spreads out the radiant energy better than any standard style reflector, which eliminates the hot spot or "dehydration zone" directly below the heater. The asymmetrical design creates symmetrical heat at the floor even when it is hung off center, and provides an EZ clean surface. We also offer unit heaters, vent free heaters, and electric heaters to provide comfort in egg rooms and other areas of your barn as well.

Advantages:

• Eliminate "Overheat Zones" under first 8' of tube

• Shorten cold gaps between heaters up to 53%

• Provide higher last tube temperatures for even heating

• Up to 55' wide, single row heating

• Symmetrical floor heat when installed off-center

COMFORTER Tube Heater Systems

The HeatStar® COMFORTER Tube Heater systems utilize infrared technology to strategically direct radiant heat to the ground level cost effectively keeping stock at the desired, comfortable temperatures.
